Key Specifications/Special Features:
- Working temperature: -29 to 180 degrees Celsius
- Structural formation: BC
- Operating: manual operated, electric actuated
- Designs: API 599 and API 6D
- Face to face: ASME B16.10
- Flange end: ASME B16.5
- Test and inspection: API598 and API6D
- Body and bonnet: cast steel ASTM A216 WCB, stainless steel ASTM A351 CF8, CF8M, CF3, CF3M
- Stem and plug: ASTM A182 F6a, ASTM A182 F22, ASTM A182-F304, F316, F321, F304L and F316L
