Triple offset butterfly

Key Features:

1. Triple Offset Design:

   • Bubble-Tight Seal: The triple offset design eliminates friction between the disc and seat during operation, ensuring a tight, bubble-tight seal and zero leakage.

   • Reduced Wear: The offset design minimizes wear on the sealing surfaces, extending the valve's service life and reducing maintenance costs.

2. Carbon Steel Construction:

   • Durability: Carbon steel provides exceptional strength and resistance to wear, corrosion, and high-stress environments, making it suitable for harsh industrial applications.

   • High-Temperature and High-Pressure Resistance: Carbon steel ensures reliable performance in extreme temperatures and pressures.

3. Flange End Connection:

   • Secure Installation: The flange end connection ensures a strong, leak-proof joint, making it easy to install and integrate into existing piping systems.

   • Versatility: Compatible with various flange standards (e.g., ANSI, DIN, JIS), allowing for use in a wide range of applications and regions.

4. Metal-to-Metal Seal:

   • High-Performance Sealing: The metal seat provides excellent sealing performance, even under high-temperature and high-pressure conditions.

   • Corrosion and Erosion Resistance: The metal seal is highly resistant to corrosion and erosion, ensuring long-term reliability.

5. Gear Wheel Operator:

   • Precise Control: The gear wheel mechanism allows for smooth and precise operation, enabling accurate positioning of the valve disc.

   • Mechanical Advantage: The gear-driven design provides high torque output, making it easier to operate the valve in high-pressure or large-diameter applications.

6. Bidirectional Sealing:

   • Versatility: The valve is designed to handle bidirectional flow and pressure, making it suitable for applications where flow direction may change.

Applications:

• Oil and Gas: Ideal for upstream, midstream, and downstream applications, including pipelines, refineries, and offshore platforms.

• Power Generation: Suitable for power plants, including fossil fuel, nuclear, and renewable energy facilities.

• Chemical and Petrochemical: Used for handling corrosive and high-temperature fluids in chemical processing plants.

• Water and Wastewater: Effective in water treatment and wastewater management systems.

• Marine and Shipbuilding: Suitable for marine applications requiring robust and reliable valves.

Advantages:

• Zero Leakage: The triple offset design and metal-to-metal seal ensure a bubble-tight seal, even under extreme conditions.

• High Durability: Carbon steel construction provides exceptional resistance to wear, corrosion, and high temperatures.

• Precise Operation: The gear wheel operator ensures smooth and accurate control, enabling optimal flow regulation.

• Secure Installation: The flange end connection ensures a strong, leak-proof, and easy-to-install solution.

• Bidirectional Capability: Suitable for applications with changing flow directions, providing consistent performance.
